VBOX Video Data Loggers provide advanced integrated video and data acquisition, fully synchronised HD video and measurement data in real time. The VBOX Video HD2 features 1080p/30fps video, a 25 Hz GPS receiver, and live graphical overlays, ideal for vehicle dynamics, ADAS validation, and performance testing.
Applications
- ADAS Testing: precise line crossing detection, multi-camera support.
- Brake & Tyre Testing: real-time heat-map overlays.
- Handling & Dynamics: full vehicle view with synchronised video and data.
Key Specifications
- GPS update rate: 10–25 Hz
- Video: 1080p/30fps, up to 4 cameras
- Velocity accuracy: 0.1 km/h
- Velocity resolution: 0.01 km/h
- Distance accuracy: 0.05%
- Distance resolution: 1 cm
- Maximum acceleration: 4 g
- Heading accuracy: 0.3°
- CAN channels: up to 80
