Delivery measuring instrument to a seminconductor customer

09/05/2025

As a key manufacturing center of Samsung Group, Samsung Electro-Mechanics Vietnam (SEMV) specializes in manufacturing and assembling high-density interconnected printed circuit boards (HDI) (including FPCB and Main board) and components and spare parts such as camera modules, etc., supplying the global market. Operating in this high-tech field requires SEMV to maintain a manufacturing environment where absolute precision and uncompromising quality control are the core foundation.

To ensure that each product that leaves the factory meets international quality standards, every process at SEMV, from micro-assembly to functional testing, is monitored and inspected with the highest level of rigor. In this context, the ability to measure precisely down to the smallest detail and closely control technical parameters becomes extremely important, especially when recording extremely small impact forces - a key factor that directly affects the performance and reliability of the final product. To realize these outstanding quality and precision standards in each product, Samsung Electro-Mechanics Vietnam (SEMV) must address very specific technical requirements.

One of the key requirements is the ability to reliably measure and control extremely small interaction forces, especially those that arise below 0.6 Newton (N) in critical manufacturing and inspection processes. Accurate measurement at this ultra-low force range requires equipment with exceptionally high sensitivity, stability, and measurement repeatability.

HIKI TEC., JSC has consulted and implemented a specialized measurement solution, integrating 2 high-tech devices from Kistler:

  • Kistler 9313AA1 ultra-small piezoelectric force sensor: Specially selected for its wide measuring range (0...5000 N) and outstanding piezoelectric sensitivity, the 9313AA1 sensor is capable of accurately detecting and recording extremely small force changes, fully meeting measurement requirements below 0.6N. https://kistler.cdn.celum.cloud/SAPCommerce_Download_original/000-705e.pdf
  • Kistler 5867B0010 Process monitoring system: Playing a central role in data collection and analysis, this device monitors and processes sensitive signals from the 9313AA1 sensor with high precision and stability, providing accurate force data to SEMV's quality control and evaluation system. https://kistler.cdn.celum.cloud/SAPCommerce_Download_original/003-054e.pdf

The combination of the ultra-sensitive sensor 9313AA1 and the advanced signal processor 5867B0010 forms a complete measurement system, providing an optimal and efficient solution for the problem of measuring ultra-small energy at Samsung Electro-Mechanics Viet Nam.
