The OXTS RT3000 v4 is a premium GNSS/INS for projects that require robust, highly accurate, out-of-the-box localisation. It combines survey-grade GNSS with OXTS’ most accurate IMU10 to produce dependable real-time navigation data.
RT3000 v4 reaches specification after around three minutes of low-dynamic motion, reducing setup time in the field. The platform also includes free NAVsuite software, ISO 17025 calibration options, RT-Range compatibility and variants such as 16g, Terrastar corrections and DO-160 for harsher environments.
Applications
- ADAS and vehicle dynamics testing
- Precise localisation in harsh GNSS environments
- Surveying, mapping and georeferencing
- Aerospace and rugged deployments using the DO-160 option
Key specifications
- Position accuracy: 0.01 m
- Heading accuracy: 0.04°
- Pitch/Roll accuracy: 0.01°
- Position after 60 s GNSS outage (PP): 0.50 m
- Slip angle accuracy: 0.05°
- Core configuration: dual survey-grade quad-constellation GNSS, IMU10, Gx/ix aiding, embedded NTRIP client
- Key capabilities: IP65 case, low-dynamics warm-up, free NAVsuite, ISO 17025 calibration
