Piezoresistive high pressure sensor, Type 4067E

High pressure sensor with robust diaphragm and front seal for measurements at hydraulic systems (e.g. injection systems of combustion engines). Suitable for static and dynamic pressure.

Ứng dụng:

The sensor Type 4067E...DS is used in applications where high pressures must be measured with a static and a dynamic component. Examples include:

Frequency-accurate analysis of pressure profiles in diesel injection systems with unit injector or common rail technology

General pressure measurement on hydraulic systems with average to high pressures

Thông số kỹ thuật:

• Measuring range: 3000 bar.
• Overload: 3500 bar.
• Natural frequency: >200 kHz.
• Linearity : ≤±0,3 %FSO.
• Mounting thread: M10x1.
• Amplifier compatibility: Type 4665, 4665B, 4624A
